2G / 3G / 4G Rugged Industrial PDA , Android Handheld Long Range UHF RFID Reader

Beijing Speedata Technology Co., Ltd
Contact Now

2G / 3G / 4G Rugged Industrial PDA , Android Handheld Long Range UHF RFID Reader

  • 1
  • 2

Brand Name : SPEEDATA

Model Number : SD60RT

Certification : CCC, CE, ROHS, FCC, BIS

Place of Origin : Shenzhen, China

MOQ : 1pcs

Payment Terms : T/T, MoneyGram, Western Union

Supply Ability : 10000pcs per month

Delivery Time : 5-8 working days

Packaging Details : Standard

Product Name : Long Range RFID Reader

Operating System : Android 11

SDK : Available to Offer

 CPU : Octa-core 2.0GHz

Memory capacity : 2GB/4GB RAM+16GB/64GB ROM

Display : 6.0 inch HD IPS LCD

Display Resolution : 2160*1080

Communications : 2G/3G/4G/Wi-Fi/Bluetooth

Dual-band WiFi : IEEE 802.11 a/b/g/n 2.4G 5G dual frequency

SIM Card Slot : 2*SIM

Battery : Master: 6000mAh Handle: 4000mAh

Option 1 : Barcode Scanner

Option 2 : LF/HF/NFC/UHF RFID Reader

Option 3 : PSAM

Contact Now

2G / 3G / 4G Rugged Industrial PDA , Android Handheld Long Range UHF RFID Reader


Advantages of SD60RT Android Handheld PDA:

SD60RT is an ultra rugged Android pda that handles any environment. It is an all-in-one pda with integreted barcode scanner, UHF RFID reader, and NFC reader, etc. Besides, it also has the basic functions like a camera, a phone and so on. You will find it a great help with you work.

2G / 3G / 4G Rugged Industrial PDA , Android Handheld Long Range UHF RFID Reader

SD60RT Basic Parameters
OS Android 8.1
CPU Octa-Core 2.0GHz
RAM 2GB/4GB
ROM 16GB/64GB
Expansion Micro SD (TF) card slot up to 128GB
Keypad 2 audio buttons+2 function buttons(One on the left and one on the right)+ 1 power
button+1 handle button
Notification Sound/vibration/LED prompt
Audio Front dual stereo speakers
Volume 90db±3db(test distance 10cm)
Dimentions 160*80*15.8mm(handle length 110mm)
Weight( with battery) 600g
Camera
Camera Rear camera 13MP AF+High brightness LED flash+Front Camera 5MP FF
Focus mode Autofocus ; Fixed focus
Display
Display 6.0 inches,IPS high light screen
Resolution 2160*1080
Touch Panel 5-point capacitive touch screen
Power
Battery Capacity Master:6000mAh Handle:4000mAh
Charging PE fast charging, full charging time< 4 hours
Interface 2Nano SIM cards,
1micro SD card slot up to 128GB,
USB-Type C, support fast charging, OTG,
Support fast charging5V/9A 1.67A,
charging and bottom USB connector
Communication
Bluetooth BT4.1 BLE
WLAN WiFi 802.11 a/b/g/n 2.4G 5G Dual Frequency
WWAN FDD-LTE B1/B3/B5/B7/B8
TDD-LTE B38/B39/B40/B41
TDSCDMA B34/B39
WCDMA B1/B2/B5/B8
GSM B2/B3/B5/B8
CDMA1x/CDMA2000 BC0/BC1
GPS Positioning Module GPS+BD+GLONASS
Performance
Operation Temperature -20℃ ~55℃
Storage Temperature -30℃ ~+70℃
Humidity 5%~95%(No condensation)
Sealing IP65
Drop Test 6 sides can withstand the impact of 1 meters drop to the concrete floor
ESD ±15kV Air Discharge, ±8kV Contact Discharge
Certificate CCC,CE,ROHS,FCC,BIS
Extensibility
NFC Support agreement:ISO14443A/B, ISO15693
reading distance: 0~5cm
RFID
( ultra high frequency )
Protocol standard: EPC G2/ISO 18000-6C;
Working frequency: China (920-925MHz);
North America (902-928MHz);
Euro frequency (865-867MHz);
Antenna parameters: 4dBi four-arm spiral;
Power: working voltage 3.6V-5V,RF output
5dBm to 30dBm(1W), 1dBm adjustable;
Standby power consumption is about 0.25W,
maximum 7.5W (typical 7W);
Card reading distance: indoor > 18m;
Outdoor environment >8m;
Group read rate > 200 tags per second;
Code Scanning
Support Code System

CM60, Support code system:EAN13

EAN8, UPCA, UPCE, Code 128, Code 39

Codabar, UCC/EAN128, RSS,ITF, ITF14, ITF6

ISSN, ISBN, Standard 25, Matrix 25

Industrial 25,Plessey, MSI Plessey, Code 11

Code 93, PDF417, QR Code, DataMatrix

AZTEC, Hanxin Code, Maxicode, Micro QR

Micro PDF417, Composite

PSAM Support
Sensor Geomagnetism, acceleration, optical distance
Explosion-proof(optional) Sign of explosion-proof:Ex ib IIC T4 GB
Certificate number:CCRI 19.2205X
DC60RT
Single charging base (optional)
input: 5V / 9V 1.67A
