Hand Held Industrial Pda With Barcode Scanner And GPS&NFC For Express Delivery And Warehouse
Products Introduction
SD35 is an industrial pda basis on Android 8.1 OS, it can integrate multiple functions: 1D/2D Barcode Scanner, Fingerprint Scanner, UHF Reader, Thermal Printer etc. Customers are able to order their own SD35. It's a universal model, it supports custom service to meet different demands.
Prducts Features:
| ◆ Side quick scan button,operation by one hand and easy trigger.
◆ Equipped with keyboard, hand glove operation.
◆ 30 ° angle scanning design, comfortable use.
◆ Can choose NewLand: CM60 Scan engines.
◆ 5200mAh large capacity battery, stable endurance.
◆ Support GPS,Beidou,GLONASS. |
Specifications
| SD35 Basic Parameters |
| OS | Android 8.1 |
| CPU | Octa-core 2.0GHz |
| RAM | 2GB |
| ROM | 16GB |
| Expansion | Micro SD (TF) card slot up to 128GB |
| Keypad | 35 physical buttons(include 5 side buttons) |
| Notification | Sound, Vibration, LED prompt |
| Audio | Built-in speaker |
| Dimentions | 184*70*29.8mm |
| Weight( with battery) | 290g |
| Camera |
| Camera | Rear Camera 13MP |
| Focus mode | Autofocus |
| Flash | Support single color LED Flash |
| Display |
| Display | 5.0" IPS LCD |
| Resolution | 640*960 |
| Touch Panel | 5-point Capacitive Touch Screen |
| Backlight | LED backlight |
| Power |
| Battery | 5200mAh |
| Charging | DC dedicated charger 9V/1.2A |
| Communication |
| Bluetooth | BT4.1 BLE |
| WLAN | IEEE 802.11 a/b/g/n 2.4G 5Gdual frequency |
| WWAN | FDD-LTE B1/B3/B5/B7/B8 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0/BC1 |
| GPS | GPS+BD+GLONASS |
| Performance |
| Operation Temperature | -20°C to 55°C |
| Storage Temperature | -30°C to +70°C |
| Humidity | 5%~95%(No condensation) |
| Sealing | IP65 |
| Drop Test | In the operating range, 6 sides can withstand the impact of 1.5 meters
drop to the concrete floor |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge |
| Certificate | CCC,CE,ROHS,FCC |
| Extensibility |
| NFC RFID Reader | NFC (PN547) : 13.56MHz reader and writer,ISO 14443A/B, ISO 15693 MIFARE |
| Reading Distance | 5cm-40cm according to barcode model and size |
| RFID Reader | 2. NFC (PN547) : 13.56MHz reader and writer,ISO 14443A/B, ISO 15693
Reading distance: 0cm-5cm
|
| Thermal printer | Roll width ±58mm, roll thickness 40mm |
Products Details
Speedata Services
As a listed company from china manufacturer, we support you:
Completely Free SDK and technical support for you.
ODM/OEM customization services according to your needs.
13 months warranty for your devices and other parts. and 6 months for the batteries. Exend warranty,it'll cost 0.5% for each per year.
Free maintenance of the devices and part of accessories replacement in the warranty .if out of the warranty, you'll have to pay the basic cost for them.
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy, the cheaper it'll be.
The sample price is a little bit higher than the common wholesale price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly producing industrial PDA Terminal Hardware and as a software solutions supplier with over 8 years' OEM/ODM experience. We are also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode Scanner.
We also provide ODM/OEM Customization Services based to your demands.
We support 13 months Warranty for all the device and 6 months for the batteries. Exend warranty, it costs 10% at the first year, and 15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile, Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more and more positive feedbacks from our customers.
